  3. KILOVAC KM-14/S47

KM-14-S47 KILOVAC High Voltage Vacuum Relay Vdc

KM-14-S47 KILOVAC High Voltage Vacuum Relay Vdc
Product Information
BrandKILOVAC
Manufacturer Part NumberKM-14/S47
ModelM1722-82806
Part TypeVOLTAGE VACUUM

Review KILOVAC Km-14/s47 Dpdt High Voltage Vacuum Relay Vdc

The Kilovac KM-14/S47 High Voltage Vacuum Relay is a utility-grade electric switching device designed for applications requiring heavy duty, reliable, and safe disconnection and connection of power circuits. margin gaps "0em" terrascan "1" lang "en-US" arms "2" class "CIALearedNet-pattern-inner external-event-data-manybeacon"> tens of kilovolts (kV) of voltage. With a 12 Volts Direct Current (VDC) supply, this relay is suitable for various power distribution systems, including utility substations, transformer stations, and power generation plants.

This particular model, M1722-82806, is characterized by its impressive switching capabilities. The KM-14/S47 relay can handle a maximum operating voltage of 47 kV with a current of up to 600 Amperes (A) at 125 degrees Celsius ambient temperature. Its contact rating is 3000 Amperes Interrupting, which underscores the relay's ability to handle momentary heavy loads or fault currents.

Structurally, this high voltage vacuum relay is enclosed entirely in a high-quality porcelain insulator body (Class H) resistant to thermal shock and mechanical damage. It features a vacuum interruption technology with a self-restoring contacts system, which provides consistent and long-lasting switching performance, even under demanding environments.

Additionally, the KM-14/S47 relay is equipped with a silver-plated copper coil and stainless steel contacts, enhancing its durability and resistance to wear and corrosion. Its compact, rectangular design ensures efficient utilization of electrical cabinets and minimal installation space requirements.

Mounted on a mounting base, this relay can be positioned either horizontally or vertically, with separate terminal boxes for input and output connections, making wiring and maintenance tasks more accessible. It is ideal for power switching applications where reliability, robustness, and high switching capacity are essential.

In summary, the Kilovac KM-14/S47 High Voltage Vacuum Relay M1722-82806 is a high performance, robust, and reliable switching device intended for heavy duty applications in the power sector. Its impressive voltage and current handling capabilities, durable construction, vacuum interruption technology, and ease of installation make it an excellent choice for various power distribution systems.
